HFO semi-private vinyl fence

Deqing Huazhijie Railing & Fencing Co., Ltd. has manufactured PVC fencing from our plant in Deqing, Zhejiang, near Shanghai, since 2003. Extrusion, cutting, hole drilling, notching and packing all run under one roof across our 4,800 m² facility, and the HFO profile is part of our daily vinyl fence production rather than an occasional special. The section is built for boundaries that need a clear line and screening at eye level without turning a yard into a solid wall: side yards, property divisions, pool surrounds, estate and community perimeters, and light commercial landscaping.

Every order is a full component system — lead-free virgin PVC profiles, pre-routed posts, pre-notched rails, pickets, post caps and matching gates. Height, width, picket spacing and colour follow the project instead of a fixed catalogue frame, and we take OEM and ODM work for private-label fencing programmes.

Where the HFO Semi-Private Layout Performs

As a Hfo Semiprivate Vinyl Fence manufacturer, we match product configuration to the application, operating limits, interfaces and acceptance criteria defined for each project.

Semi-private fencing is chosen when full privacy panels would block light, air movement or sightlines that the site actually needs. The HFO structure keeps an open band while still marking the boundary hard enough to guide traffic, contain pets and define maintenance responsibility.

• Residential side yards and driveway edges where neighbours keep a view through the upper section.
• Pool and deck surrounds that require a defined perimeter without a closed wall effect.
• Community, estate and park boundaries where consistent elevation matters across long runs.
• Commercial forecourts, rental properties and managed landscapes that need low-maintenance perimeter fencing.

HFO Section Specification

The values below describe a standard HFO section. Metric figures are conversions of the imperial profile dimensions we cut to.

Material Formulation and Finish

Profiles are extruded from 100% virgin PVC with no recycled content and no lead. UV inhibitors, impact modifiers and stabilisers carry the weathering performance, and the titanium dioxide system is what keeps the surface from chalking under long sun exposure. Raw materials are traceable, including US DuPont TiO₂ and US or German brand pigments.

• No rust, rot, termite damage, chipping or peeling over the service life of the fence.
• Formulation rated for a −40 °C to 70 °C service range, so the same profile suits cold Canadian winters and hot Australian summers.
• Wind performance depends on fence style, post embedment and rail configuration — we review the exposed site conditions with the configuration, not in isolation.
• Surface cleans with water and detergent; graffiti and stubborn marks respond to mild abrasive cleaners or a pressure washer.

Configuration Options and Matching Profiles

The HFO section is quoted as a kit: all rails and pickets for the section, with posts, caps and gates specified separately against the layout. As a HFO semi-private vinyl fence manufacturer we build both the standard elevation and the variations below, and we align the choice with the privacy level and wind exposure the site actually has.

• Picket spacing and picket face width — tighter spacing for more screening, wider spacing for a lighter, more open line.
• Post routing — line, end, corner, 3-way or blank posts, counted from the layout drawing.
• Cap profile — New England, Flat or Gothic, in the same colour as the panel.
• Height and width — non-standard sections are cut to the run rather than adjusted on site.
• Adjacent semi-private options — HFB PVC semi-private fence panels and the HFC louvered semi privacy fence for elevations that need a different slat or louvre rhythm.
• Full privacy alternates — a HEA PVC privacy panel fence 6'×8' where a run must switch to a closed panel.

Installation Sequence and Site Interfaces

Rails arrive pre-notched and posts arrive pre-routed, so the installer sets out post centres, drops the rails into the post routing, slides the pickets into the notches and fixes the caps once the run is level. Component preparation is done in our factory during cutting, drilling and notching, which keeps picket spacing consistent across the whole elevation. Vinyl posts are set the same way as wood posts in the local market; where concreting wood posts is standard practice, vinyl posts are concreted to match.

• Confirm post positions and types before excavation — line, end and corner posts are not interchangeable.
• Gate posts carry the leaf load and are quoted separately from the standard run.
• Sloped ground is handled by stepping the elevation or by a racked section, decided during configuration.
• Post caps go on last, after the section is fixed and aligned.

Quality Control, Certification and Acceptance

An independent quality-control group inspects every extruder’s production hourly and examines finished profiles on a random basis. Because extrusion through packing sits inside our own plant, the same team follows a section from raw material batch to the export carton, and material lots remain traceable back to their source.

• Certification held for the product and material lines includes CE, RoHS and UL94.
• Quality-system and manufacturer evidence includes SGS, ASTM, ISO 9001 and TUV global manufacturer certification.
• Acceptance documentation supplied per order: component list, packed quantities, container loading plan and the certificates relevant to the shipment.
• Production sequence followed on every run: extrusion, cutting, drilling, notching, packing, storage.

Packing, Loading and Delivery Scope

Each section takes 0.166 CBM, which gives a working figure for container planning before the order is packed. Panel kits ship with all rails and pickets for the section; posts, caps and gates are packed as separate line items so the site receives exactly the quantities on the layout drawing. We confirm the loading quantity against the container size you nominate and issue the loading plan with the shipping documents.

Maintenance, Spare Parts and Long-Life Support

Maintenance is deliberately light: a garden hose rinse handles normal dirt, a mild abrasive cleaner handles weather staining, and a pressure washer handles heavier build-up. Damaged pickets, rails, posts and caps are supplied as individual replacement parts rather than whole sections. Fence and railing systems carry our 30-year limited warranty, and installation video guidance is provided so that fabricators and site crews work from the same assembly sequence we build to.

New profiles and styles are developed from customer drawings, and OEM or ODM requests are handled through the same extrusion and tooling route as our catalogue sections.

Information We Use to Configure Your Solution

Send these details with your enquiry and we return a configured section list, gate schedule and container loading estimate rather than a generic price sheet.

• Run lengths with the position of line, end, corner and 3-way posts, plus total post count.
• Finished height and section width, or the drawing dimensions if they differ from 72 in × 96 in.
• Colour and cap profile.
• Picket spacing and whether the mid-band should be the 2 in × 3-1/2 in rail or the 7/8 in × 6 in band.
• Gate quantity, leaf width, hinge side and latch requirement.
• Ground conditions, slope handling and exposed wind conditions.
• Order quantity, destination port and any private-label or OEM marking.

Frequently Asked Questions

What is the standard HFO semi-private vinyl fence section size?

A standard section finishes at 72 in high and 96 in wide, built from three 2 in × 3-1/2 in × 94 in pre-notched rails and 13 pickets at 7/8 in × 6 in × 68 in. Heights and widths outside that are produced to order.

Which posts does the fence need, and how are they prepared?

Posts are 4 in × 4 in or 5 in × 5 in and arrive pre-routed as line, end, corner, 3-way or blank. Send the layout and we return the post schedule by type and quantity.

Can the fence be produced in a custom colour or under our own brand?

White, Tan, Grey and Cream are our standard runs. We also accept OEM and ODM orders, including private-label packing and new profile development from customer drawings.

Does a matching gate come with the fence?

Yes. Gates are made to match the panel in colour and profile. Specify leaf width, hinge side and latch type so the gate posts are routed correctly.

How is the order packed and how much container space does it take?

Each section occupies 0.166 CBM. Panel kits contain all rails and pickets for the section, with posts, caps and gates packed as separate items, and we issue a loading plan based on the container you nominate.

What support is available after delivery?

Fence and railing systems carry a 30-year limited warranty. Replacement pickets, rails, posts and caps are supplied individually, and installation video guidance covers the assembly sequence used in our factory.
