HFP lead-free plastic fence

Deqing Huazhijie Railing & Fencing Co., Ltd. has produced PVC fence profiles in Huzhou, near Shanghai, since 2003, and the HFP lead-free plastic fence is one of the semi-private systems we extrude, notch and kit in our own plant. HFP ships as a complete section: pre-routed posts, pre-notched rails, 7/8" x 6" pickets, post caps and matching gates, built to a 72" standard height and 96" standard width. It is the panel we supply for residential boundaries, pool surrounds, commercial perimeters and multi-unit developments where screening is wanted without closing a property off.

Semi-Private Screening: What the HFP Panel Does

As a HFP Leadfree Plastic Fence manufacturer, we match product configuration to the application, operating limits, interfaces and acceptance criteria defined for each project.

HFP is an open picket fence rather than a solid privacy wall. Thirteen 7/8" x 6" pickets per 96" section at standard spacing interrupt direct sightlines at standing eye level while keeping air moving across the fence line — the reason it is chosen around pools, courtyards and side yards where a full tongue-and-groove panel would trap heat and block daylight.

At 72" the panel screens a standing adult from the shoulder up; shorter and taller sections are produced to order, so a run can step down at the front of a lot and rise to full screening along a rear boundary without changing the fence style.

Section Anatomy and Specification Meaning

Every dimension in the HFP kit has a job. The table below is the standard build we quote from; each line can be adjusted within the limits of the extrusion tooling.

The aluminum insert in the bottom rail is the detail that separates a residential-grade panel from a commercial one. It stiffens the rail that carries the picket load and resists sag across a 96" span, which matters on long runs, exposed sites and installations where the fence also works as a barrier.

Configuration Options We Build To

• Height: 72" standard, other heights produced to order.
• Width: 96" standard, other section widths produced to order.
• Colour: white, tan, grey and cream.
• Posts: 4" x 4" or 5" x 5", pre-routed as line, end, corner, 3-way or blank, with a 102" length option.
• Caps: New England, flat or Gothic.
• Gates: matching single and double gates on the same profile and colour.
• Kitting: panel kits include all rails and pickets; posts, caps and gates are quoted as part of the same bill of materials.
• OEM and ODM: new profiles, picket rhythms and packaging developed against customer drawings.

Projects that need a different screening density can be built from the same post and rail family — the HFA alternative semi privacy fence and the HFB PVC semiprivate fence panels share the installation logic, so a site can mix styles without mixing hardware.

Where the HFP Fence Fits

The open picket build suits boundaries where a solid panel would be the wrong answer — too much wind load, too little light, or a need to keep an eye on what is happening beyond the line.

• Rear and side boundaries on detached and semi-detached housing.
• Pool and spa surrounds, where airflow and visibility into the water area matter.
• Rental property, commercial and light industrial perimeters that need a repeatable module.
• HOA and multi-unit developments specifying one consistent section across many lots.
• Parks, gardens and estate frontages where a lighter visual line is preferred.

Where a pool or terrace needs a railing rather than a panel, the HBA PVC vertical railing fence uses the same material system and post routing, which keeps a mixed site visually coherent.

Material Formulation and Weather Performance

HFP profiles are extruded from 100% virgin PVC with no recycled content and no lead-based stabiliser, which is what the lead-free designation refers to. The formulation carries UV inhibitors, impact modifiers and stabilisers alongside the resin, and the raw materials we use are traceable back to their source.

• DuPont titanium dioxide at 10 parts per 100 for non-chalking surface performance.
• US or German brand pigments for colour retention across white, tan, grey and cream.
• Service temperature range of -40°C to +70°C, covering cold-weather and high-sun markets.
• No rot, no termite damage, no painting or staining over the life of the fence.

Extrusion, Quality Control and Acceptance

Production runs through extrusion, cutting, drilling, notching, packaging and storage, and each stage is controlled in-house rather than subcontracted. Our quality group inspects every extruder's output hourly and pulls additional random samples through the shift, so wall thickness, colour and notch position are checked while the line is running, not only at final packing.

• CE, RoHS and UL94 documentation available for the relevant profiles.
• SGS and ASTM test documentation, ISO 9001 quality system certification and TUV global manufacturer certification.
• 30-year limited warranty on the fence system.
• Pre-shipment inspection against the confirmed bill of materials, including section counts, post routing and cap quantities.

Installation and Site Interfaces

Posts arrive routed and components arrive precut, so assembly follows the same sequence as a wood fence: set the posts, drop the rails into the routed post holes, insert the pickets into the notched rails, then fit the caps. The heavier wall section and notched rails increase resistance to pullout and give a stronger fastening than a plain butt joint.

• Posts are set in concrete where local practice cements wood posts; 5" x 5" posts are used for gate posts and exposed sites.
• Gate openings need swing clearance and a post that can carry the leaf, so gate positions are fixed before the run is cut.
• Corners, ends and 3-way junctions are resolved at the routing stage, not on site.
• Video installation guidance and technical support are provided with the order.

Maintenance and Serviceability

Under normal conditions a garden hose rinse is enough. Stubborn marks come off with a mild abrasive cleaner of the type used on fibreglass tubs; graffiti usually lifts with ordinary detergent and water, a pressure washer for heavier cases, and 400 grit sandpaper for the last traces. Nothing on the fence needs repainting or sealing.

Because the system is modular, a damaged picket or rail can be replaced without rebuilding the run, and replacement components are supplied in the same profile and colour as the original order.

Information We Use to Configure Your Solution

Send the following and we will return a configuration, a bill of materials and a quotation rather than a generic price list.

• Total fence line length, plus the number of corners, ends and 3-way junctions.
• Required height, section width and colour.
• Post size and routing pattern, or the site plan if routing is to be decided with us.
• Gate count, opening width and swing direction.
• Wind and snow exposure, soil or ground conditions, and whether posts will be cemented.
• Target container loading, packaging and labelling requirements, and OEM or ODM branding.
• Destination port and required delivery window.

Frequently Asked Questions

What is the standard HFP section size, and can it be changed?

The standard section is 72" high and 96" wide with thirteen 7/8" x 6" x 63" pickets at standard spacing. Other heights and widths are produced to order, and the post routing is adjusted to match the new module so the panel still assembles without site cutting.

How is the fence confirmed as lead-free?

Profiles are extruded from 100% virgin PVC with no lead-based stabiliser and no recycled content. We hold CE, RoHS and UL94 documentation for the relevant profiles, along with SGS and ASTM test documentation and ISO 9001 quality system certification, and the raw materials used in the formulation are traceable.

How much container space does an HFP fence take?

Each standard section occupies 0.166 CBM. Posts, caps and gates add volume on top of that, so loading is calculated from the confirmed bill of materials — section count, post count and gate count — rather than from a nominal figure per metre.

Do the posts need to be set in concrete?

Treat vinyl posts the same way as wood posts in your area. Where local practice cements wood fence posts, cement the vinyl posts as well. Gate posts and exposed sites are normally specified with the 5" x 5" post rather than the 4" x 4".

Can gates and caps be matched to the fence run?

Yes. Matching single and double gates are produced in the same profile and colour as the fence, and post caps are available in New England, flat and Gothic profiles so the finished run reads as one system.

Deqing Huazhijie Railing & Fencing Co., Ltd. supplies the HFP lead-free plastic fence manufacturer range from our factory in Huzhou, near Shanghai, with OEM and ODM orders welcome.
